Copper-Clad Laminates Market

Copper-Clad Laminates Market: Information by Product (Paper Board, Composite Substrate, FR-4), Type (Rigid, Flexible),End-Use (Automotive, Healthcare, Industrial),Region: Forecast Till 2026

Almost all of the electronics ranging from smartphones to X-Ray scanners have a Printed Circuit Board (PCB). These PCBs are made of Copper-Clad Laminates (CCL), which are a type of base material of PCBs, while the reinforcing material is generally gl
Report Code: SRAM535DR

Market Overview

Almost all of the electronics ranging from smartphones to X-Ray scanners have a Printed Circuit Board (PCB). These PCBs are made of Copper-Clad Laminates (CCL), which are a type of base material of PCBs, while the reinforcing material is generally glass fiber or wood pulp paper. These laminates are copper clad on either one or both sides of reinforcing material after being soaked in resin.

Copper-clad laminates are manufactured by pressing layers of filler material impregnated with resin under heat and pressure with copper foil. They are suitable for hot or cold punching and resistant to heat and moisture and exhibit excellent mechanical and electrical properties. A key application for copper-clad laminates is in the manufacture of PCBs used to mechanically support and connect electronic components. This is done by etching pathways, tracks, or signal traces onto a non-conductive substrate.

Based on the side that is functional, PCBs are usually of three types, namely single-sided, double-sided, and multilayer. Single-sided boards have a conductive pattern only on one side of the insulating substrate, while double-sided printed boards have conductive patterns on both sides. Multilayer PCBs, which are in great demand, have more than two sides of conductive patterns that are interlocked with insulating materials and interlinked in accordance with regulation.

Report Scope

Report Metric Details
Base Year 2017
Study Period 2016-2026
Forecast Period 2023-2031
Market Size
Fastest Growing Market Taiwan
Largest Market China
Report Coverage Revenue Forecast, Competitive Landscape, Growth Factors, Environment & Regulatory Landscape and Trends
Geographies Covered
  • North America
  • Europe
  • APAC
  • Middle East and Africa
Get more information on this report Download Sample Report

Regional Analysis

As per the Ministry of Industry and Information Technology (MIIT) in April 2019, China is the world’s largest producer, consumer, and exporter of consumer electronics. In 2018, China produced 1.8 billion mobile phones, 300 million computers, and 200 million televisions. All these products require PCBs, which in turn require CCLs. In November 2019, China also unveiled its 5G network, which has already been rolled out by other countries such as the U.S., the U.K., and South Korea.

PCB manufacturing in China looks promising even after the U.S.-China trade conflict and the fall in demand for smartphones and cars. According to the Taiwan Printed Circuit Association (TPCA), the output of Taiwanese PCB manufacturers generated USD 9,300 million in the first half of 2019. These manufacturers benefited from certain niche markets for which PCBs made from insulating raw materials were required.

As per the Korea Printed Circuit Association, in 2017, China, Taiwan, Korea, and Japan constituted 81.6% of the world’s PCB production, of which South Korea occupied 13% of the market. Meanwhile, the CCL market of Japan is experiencing a slight downfall, with the Japan Electronics Packaging Circuits Association (JPCA) reporting, in August 2019, that the output value of Japan’s PCB industry dropped by 6.9% to USD 2,060 million in the first half of 2019.

Regional Growth Insights Download Free Sample

Segmental Analysis

Types of CCLs

  • Paper Copper-Clad Laminates

Paper has been used as a reinforcement in a number of Printed Circuit Boards. For impregnation, phenolic resin or epoxy resin, cyanate ester, and polyimide are used. This type of CCL is lead-free and highly effective in Printed Wiring Boards (PWB) in consumer appliances such as TV and AV devices. Also, paper CCLs soaked in phenol-formaldehyde are widely used. Paper copper-clad laminates are cheap as they come in laminated tubes formed by hot rolling. They are mechanical heat-resistance and have dielectric properties, due to which they have applications in the insulation of electrical equipment and transformers.

  • High Tg Laminates

These CCL laminates have glass fiber that is dipped into thermoset epoxy resins and then covered with copper foil that is formed through heat pressing, on either one or both sides. FR-4 (FR denotes flame retardant) is a versatile high-pressure thermoset plastic laminate with a good strength-to-weight ratio. Tg is the glass transition temperature that is related to the durability of the PCB.

Following are the Tg Points of some PCBs:

  • Normal PCB Material: 130 °C
  • Medium-Tg PCB: ≈150 °C
  • High-Tg PCB: >170 °C

They are used in PCBs, power baseboards, PDPs, LCDs, TVs, refrigerators, and washing machines. Laminates with high Tg have better strength, dimensional stability, thermal decomposition, water absorption, and adhesiveness.

  • Composite Substrate (CEM-1)

This type of laminate is composed of two substrates in which the fabric is glass fiber cloth. The core material used in this type of laminate is bleached kraft paper and is suitable for punching and drilling. With technological advancements, the Comparative Tracking Index (CTI), dimensional precision and stability have improved, due to which use of CEM-1 has increased as compared to CEM-3 and FR-4 products.

  • Other copper-clad laminates

Other copper-clad laminates with different dielectrics are polytetrafluoroethylene (PTFE), matte glass and polyester (FR-6), woven glass and epoxy, alumina and polyamide. Due to decreasing size, small dissimilarities such as thickness variations, bubbles in the resin matrix, and uneven distribution of fiberglass are gaining importance. PTFE is a kind of plastic material that offers a minimum resistance and is therefore used in high speed, high-frequency applications.

5G Technology

The dawn of 5G has created a huge demand for copper-clad laminates. Even though 5G technology functions on a wide spectrum of frequencies, it requires a larger number of base stations as compared to 4G technology for the same coverage. Moreover, the PCBs used in 5G also have advanced design capabilities. As per the requirement of properties, the use of PTFE, ceramics, or hydrocarbon/ glass material is preferred over FR-4 glass-reinforced epoxy laminate materials, which are otherwise commonly used in the manufacturing of PCBs.

Top Key Players of Copper-Clad Laminates Market

There are a number of prominent global manufacturers of copper-clad laminates

  1. Kingboard Holdings Ltd
  2. Shengyi Technology (SYTECH)
  3. ITEQ Corporation
  4. Panasonic Corp
  5. Isola Group
  6. Nan Ya Plastics Corp
  8. Doosan Corporation Electro-Materials (South Korea)
  9. Grace Electron Corp (Wuxi city and Guangzhou city)
  10. Taiwan Elite Material Co. Ltd
  11. Taiwan TAIFLEX Scientific Co. Ltd
  12. UBE Industries Ltd
  13. Goldenmax International Technology Ltd
  14. Guagndong Chaohua Technology Co

Recent Developments

In Jan 2019, Panasonic introduced a halogen-free multi-layer circuit board material called MEGTRON-6. The board enables greater capacity and higher speed transmission of data communication, which is in line with the ongoing demand of 5G technology

American Standard Circuits, an advanced circuit board solutions company, announced in December 2019 that the company has started offering PCBs of up to half an inch in thickness. The demand for high voltage PCBs and PCBs for heat dissipation is increasing. The company will produce these PCBs, which have applications in the medical, automotive, industrial and defense sectors

A Chinese PCB manufacturer, Shennan Circuits, in December 2019, announced to invest USD 50.4 million to expand its production capability of HDI PCBs. This is in line with the growing demand for 5G technology

Copper-Clad Laminates Market Segmentations

By Product

  • Paper Board
  • Composite Substrate
  • FR-4
  • Halogen-free Board
  • Others

By Type

  • Rigid
  • Flexible

By Application

  • Computers
  • Communication Systems
  • Consumer Appliances
  • Vehicle Electronics
  • Healthcare Devices
  • Defense Technology

By Reinforcement Fiber

  • Glass Fiber Base
  • Paper Base
  • Composite Base

By Resin

  • Epoxy
  • Phenolic
  • Polyimide
  • Polyester (PET)
  • Fluoropolymer/PTFE
  • Polyphenylene Ether (PPE)
  • Polyphenylene Oxide (PPO)
  • Others (Polyethylene Naphthalate [PEN], etc.)

By End Use

  • Automotive
  • Aerospace & Defense
  • Consumer Electronics
  • Healthcare
  • Industrial
  • Others

By Regions

  • North America
  • Europe
  • APAC
  • Middle East and Africa

Frequently Asked Questions (FAQs)

What is the estimated growth rate (CAGR) of the Copper-Clad Laminates Market?
Copper-Clad Laminates Market size will grow at approx. CAGR of 6% during the forecast period.
Some of the top prominent players in Copper-Clad Laminates Market are, Kingboard Holdings Ltd, Shengyi Technology (SYTECH), ITEQ Corporation, Panasonic Corp, Isola Group, Nan Ya Plastics Corp, FINELINE Ltd, Doosan Corporation Electro-Materials (South Korea), Grace Electron Corp (Wuxi city and Guangzhou city), Taiwan Elite Material Co. Ltd, Taiwan TAIFLEX Scientific Co. Ltd, UBE Industries Ltd, Goldenmax International Technology Ltd, Guagndong Chaohua Technology Co, etc.
China has held a dominant position in the Copper-Clad Laminates Market, with the largest market share.
The Taiwan region is projected to exhibit the highest rate of growth in the Copper-Clad Laminates Market.
The global Copper-Clad Laminates Market report is segmented as follows: By Product, By Type, By End Use
